X Marks the Spot Where Cycling Meets Emotion

The Pinarello X5 105 Di2 has been specifically designed to maximize rider comfort and vibration absorption, thanks to the innovative use of carbon fiber layup and a redesigned rear triangle.

The secret of T700 Toray Carbon is to maintain reactivity and performances but to offer a higher dampening to absorb all road vibration. More comfort, more fun. It features a higher stack and a more compact reach, promoting a relaxed riding position that allows bike fitters to accurately fit all kinds of cyclists.

X Stays are a new Pinarello technology capable of absorbing vibrations maintaining a light weight frame with a very reactive BB stiffness. This bike fits up to 35mm tires to unlock the frames’ true potential in terms of both comfort and speed.

Pinarello understood that, while the thrust applied to both pedals is the same, the pull on the chain applies to the right side only. For this reason, all frames are optimized to compensate these unbalanced forces.

Features:

• • Carbon T700 UD
  • Endurance+ Geometry
  • X Stays
  • Tire Clearance Up To 35mm
  • Asymmetric Frame

• FRAME – Torayca T700 UD, TiCR™ internal cable routing, Italian BB, UCI approved
• CRANKSET AND CHAINRINGS – Shimano 105 Di2 12S
• FRONT DERAILLEUR – Shimano 105 Di2 12S
• REAR DERAILLEUR – Shimano 105 Di2 12S
• CASSETTE – Shimano 105 Di2 12S
• CHAIN – Shimano 105 Di2 12S
• BOTTOM BRACKET – Shimano 105
• FRONT BRAKE DISC – Shimano 105 2 pistons caliper, 160mm rotor
• REAR BRAKE DISC – Shimano 105 2 pistons caliper, 160mm rotor
• HANDLEBAR – MOST Jaguar XA TiCR
• STEM – Tiger Aero Alu TiCR
• BAR TAPE – MOST Ultragrip Evo 3mm – Black
• SEAT CLAMP – fsc frontal seat clamp
• TIRES – Pirelli P7 Sport 35-622 black 60 tpi Nylon breaker
• WHEELSET – FULCRUM Racing 800DB
• AXLES – MOST Ultralight Custom Axle 12×100 & 12×142, Tool-free removal
