X Marks the Spot Where Cycling Meets Emotion

The Pinarello X7 Ultegra Di2 has been specifically designed to maximize rider comfort and vibration absorption, thanks to the innovative use of carbon fiber layup and a redesigned rear triangle.

The secret of T700 Toray Carbon is to maintain reactivity and performances but to offer a higher dampening to absorb all road vibration. More comfort, more fun. It features a higher stack and a more compact reach, promoting a relaxed riding position that allows bike fitters to accurately fit all kinds of cyclists.

X Stays are a new Pinarello technology capable of absorbing vibrations maintaining a light weight frame with a very reactive BB stiffness. This bike fits up to 35mm tires to unlock the frames’ true potential in terms of both comfort and speed.

Pinarello understood that, while the thrust applied to both pedals is the same, the pull on the chain applies to the right side only. For this reason, all frames are optimized to compensate these unbalanced forces.

Features:

• • Carbon T700 UD
  • Endurance+ Geometry
  • X Stays
  • Tire Clearance Up To 35mm
  • Asymmetric Frame

• FRAME – Torayca T700 UD, TiCR™ internal cable routing, Italian BB, UCI approved
• CRANKSET AND CHAINRINGS – Shimano Ultegra Di2 FD R8150 12S
• FRONT DERAILLEUR – Shimano Ultegra Di2 FD R8150 12S
• CASSETTE – Shimano Ultegra Di2 FD R8150 12S
• CHAIN – Shimano Ultegra Di2 FD R8150 12S
• BOTTOM BRACKET – Shimano Ultegra
• FRONT BRAKE DISC – Shimano Ultegra R8150 2 pistons caliper, 160mm rotor
• REAR BRAKE DISC – Shimano Ultegra R8150 2 pistons caliper, 160mm rotor
• INTEGRATED HANDLEBAR – MOST Talon Ultra Light
• BAR TAPE – MOST Ultragrip Evo 3mm – Black
• SEAT CLAMP – fsc frontal seat clamp
• SEATPOST – Pinarello Aero Seatpost
• TIRES – Pirelli P7 Sport 35-622 black 60 tpi Nylon breaker
• WHEELSET – MOST Ultrafast 40
• AXLES – MOST Ultralight Custom Axle 12×100 & 12×142, Tool-free removal
